Camden CX-ED1079DL-BK Standard Depth ANSI Universal Electric Strike with Latch Monitoring - 58 to 34 Throw - Grade 1
Sale!

Camden CX-ED1079DL-BK Standard Depth ANSI Universal Electric Strike with Latch Monitoring – 58 to 34 Throw – Grade 1

Original price was: $506.67.Current price is: $148.00.

SKU: U374206148595 Category:

Camden CX-ED1079DL-BK Standard Depth ANSI Universal Electric Strike with Latch Monitoring – 5/8″ to 3/4″ Throw – Grade 1

Standard Depth Grade 1 ‘Universal’ electric strike with latch monitoring, 5/8″ to 3/4″ throw, 12/24V AC/DC, fail safe/fail secure operation, horizontal adjustment, and 3 black faceplates (CX-ESP1B-BK, CX-ESP3B-BK & CX-ESP4B-BK).

Features:
  • Centerline latch entry for cylindrical locksets.
  • Adjustable strike body
  • Selectable 12/24V AC/DC
  • Selectable fail safe / fail secure operation
  • 3 black faceplates included
  • Horizontal adjustability of strike faceplate/body Non-handed
  • Easy fit connectors for power & monitoring wires
  • Trim plate included
  • Non-handed
  • Continuous duty operation
Specifications:
Voltage 12/24V AC/DC
Current Draw 260 mA @ 12 VDC
150 mA @ 24 VDC
Static Hold Strength 1,500 Lbs.
Dynamic Strength 70 Ft-Lbs.
Endurance 1,000,000 cycles (Factory Tested)
250,000 cycles (UL Verified)
Mode Selectable – Fail Safe; Fail Secure
Operation AC – Buzz
DC- Silent
Duty Continuous
Mechanical Adjustment Strike body
Latch Monitor SPDT, 100mA @ 24V DC
Dimensions 3.25″L x 10.51″W x 2.25″H
Downloads:
  • Specifications Sheet
